Straight Boom Harbor Crane Pedestals and Platform
Stiff bow free booms with the dexterity for accurate, safe, and
efficient material
handling. Stiff boom cranes are typically used in dock, on fixed
installations and
in harbor conditions.HAOYO stiff boom cranes are suitable equipped
on the deck
for bulk cargo ships or offshore with enough free space.
Specification
1.Working condition:
-Working temperature: -25°~40°
-Power supply: 3ph, 380v, 50HZ or according to customer's demands
-Working duty: A5-A7
-Control model: cabin room, remote control and both
2.Safety protection:
Overload protection system
Main lifting motor with thermal protection
Hooks with latch
Rubber buffers
Protective earthing.
Advantanges and Features
1.Variable speed, Soft starter, Slipring motors;
2.Wireless Radio Remote control;
3.Shrouded DSL system for power feeding;
4.Flameproof, Cabin Operated;
5.PLC automatic Control system;
6.High quality carbon steel Q345;
7. Port crane design adopt european technology;
8.All electrical applicance adopt china first-class brand,
Siemens,Schneider or according to your demands.
Drawing of Straight Boom Harbor Crane Pedestals and Platform
Technical Parameters of Straight Boom Harbor Crane Pedestals and Platform
| Crane Type | Outreach(m) | Lifting capacity(kg) | Lifting moment(kNm) | Total Moment (kNm) | Pedestal Outer Diameter (mm) | Dead Weight (kg) |
| HC200 | 6-16 | 3.5-0.9 | 144-210 | 270 | 885 | 2.7-3.2 |
| HC400 | 6-16 | 5.6-1.7 | 288-336 | 424 | 885 | 3.2-3.7 |
| HC600 | 6-20 | 10-2.3 | 460-600 | 737 | 1095 | 4.4-5.5 |
| HC 900 | 6-20 | 14.2-3.2 | 640-852 | 1039 | 1325 | 5.9-7.0 |
| HC1200 | 6-24 | 19-3.5 | 840-1140 | 1409 | 1490 | 7.8-10.2 |
| HC1500 | 7-24 | 20.3-4.6 | 1104-1421 | 1765 | 1490 | 9.2-11.3 |
| HC1800 | 7-24 | 25.6-5.4 | 1296-1792 | 2202 | 1770 | 11.4-14.1 |
| HC3000 | 21 | 12.5 | 2625 | 3750 | 1775 | 24.8 |
| HCK220 | 27,5 | 20,0 | 2200 | 4000 | 1800 | 15.0 |
| HCK300 | 30.0 | 25.0 | 3000 | 5000 | 2065 | 17.5 |
| HCK400 | 32.0 | 30.0 | 4000 | 6300 | 2050 | 20.0 |
| HCK500 | 35.0 | 35.0 | 5000 | 8000 | 2240 | 25.0 |
| HCK800 | 40.0 | 50.0 | 8000 | 11500 | 2271 | 45.0 |
