Top Weight 1t Maximum Lifting Capacity 5 Tons Telescopic Marine Crane for Sale

Ask Lasest Price
Brand Name :	HAOYO
Model Number :	HAOYO
Certification :	ABS,BV,CCS,DNV,LR,NK
Price :	USD30000/Set
Payment Terms :	T/T,L/C
Supply Ability :	300 UNITS
Delivery Time :	90days

Add to Cart

Product Details
Company Profile

Top Weight 1t Maximum Lifting Capacity 5 Tons Telescopic Marine Crane for Sale

Top Weight 1t Marine Telescopic Boom Ship Deck Crane Factory Price for sale

Product Description

HAOYO Telescopic boom cranes can work under any sea condition for its robustness

and operation flexibility. All the loading in any working radius is completely safe even

though handling loads is very close to SWL of crane.The advantages of the telescopic

cranes are low weight and less complex design making them maintenance-friendly.

As a direct manufacturer we can give you a low price and control the deliver time technical

section can design as your requirements with your work situation .Every parts will use

the top material to make sure the crane performance perfect ,besides we will give you

a guarantee period for 18 months and engineers available overseas.If you have any

problem or interest pls contact me.

Top Weight 1t Maximum Lifting Capacity 5 Tons Telescopic Marine Crane for Sale

Product Drawing

Top Weight 1t Maximum Lifting Capacity 5 Tons Telescopic Marine Crane for Sale

Technical Parameters

Component	Brand	Origin
Multitandem valve	Nord Danfoss HBS	Sweden Danmark Italy
Oil Pump	Leduc PZB OMFB	France Italy Italy
Balance valve	HBS VALLA	Italy Italy
High pressure hose	Eaton Manuli	USA Italy
Sealing	Trelleborg	Germany
Electric motor	ABB Siemens	China

MODEL	Safety Load (KN)	Max Outreach (m)	Lifting Speed(m/min)	Slewing Speed (r/min)	Luffing Time (s)	Hoisting Height (m)	Slewing Angle(°)	Permissible Heeling(transverse/ longitudinal)(°)	Power (kW)
10	10	6~20	15	1	60	30	360°	2° /5°	7.5
15	15	8~22	15	1	60	30	360°	2° /5°	11
20	20	5~24	15	1	60	30	360°	2° /5°	15
30	30	8~25	15	0.9	70	30	360°	2° /5°	22
50	50	12~25	15	0.75	80	30	360°	2° /5°	37
80	80	12~25	15	0.75	100	40	360°	2° /5°	55
100	100	12~25	15	0.75	110	40	360°	2° /5°	75
150	150	12~28	15	0.6	110	30	360°	2° /5°	90
200	200	16~30	15	0.6	120	35	270°	2° /5°	75*2
250	250	20~35	15	0.5	130	40	270°	2° /5°	90*2
300	300	35	15	0.4	140	40	270°	2° /5°	90*2
350	350	20~40	15	0.5	150	45	360°	2° /5°	110*2
400	400	20~40	15	0.5	150	45	360°	2° /5°	140*2
450	450	25~40	15	0.45	160	50	360°	2° /5°	140*2
500	500	20~40	15	0.45	170	50	360°	2° /5°	165*2

Certifications


Other Products

Top Weight 1t Maximum Lifting Capacity 5 Tons Telescopic Marine Crane for Sale

Packaging & Shipping

Top Weight 1t Maximum Lifting Capacity 5 Tons Telescopic Marine Crane for Sale

Shipping details

♦ check all the items and packaged well before loading.

♦ You can check loading or send picture to you.

♦ After shipping make documents for you,like B/L,packing list,voice according

to your requirements.
